Havit HV9660-12V60W Triac Dimmable LED Driver - 12V, 60W
Genuine Havit indoor LED driver with triac dimming. Converts 240V mains to 12V DC constant voltage for LED strip, cabinet lighting and low voltage fittings, and dims from a standard wall dimmer rather than needing a special controller.
Features
Triac dimmable - works with leading or trailing edge wall dimmers
Dimming range 10% to 100%
Supplied complete with flex and plug - no hard wiring needed
Constant voltage 12V DC output
Short circuit, overload, over current and over temperature protection
Specifications
Brand: Havit Lighting
Catalogue number: HV9660-12V60W
Input: 240V AC
Output: 12V DC constant voltage
Output power: 60W
Recommended maximum load: 48W
Recommended minimum load: 6W
IP rating: IP20 - indoor use only
Warranty: 3 year replacement
Sizing your driver
Do not run the driver at its full rated output. Add up the wattage of everything on the circuit and keep it at or under the recommended maximum load of 48W. Running a driver flat out shortens its life. Stay above the 6W minimum too, or the dimming will be unstable.
Installation
Mount in a dry, ventilated position with access for future replacement. Electrical work must be carried out by a licensed electrician.
